KEY FEATURES
- HDMI 1.3 protocol compliant
- 4 HDMI input and 1 HDMI display sink. Blue-Ray 24fs/ xv-YCC support
- Support deep color 36bit and signal retiming
- 25m AWG26 HDMI input & 20metre AWG26 HDMI output cable length
- DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD audio format
- Manual or Remote: Select one of 3 different HDMI signal input source, output to the sink
- It can smartly choose the signal source with priority order or jump over those input sources
which are not in work
SPECIFICATIONS
OP HKSW0401PH | |
HDMI version | HDMI1.3 |
HDCP version | HDCP1.2 |
Support HDMI resolution | 1080P/1080i/720P/576P/576i/480P/480i |
Support video color format | xv-YCC/deep color 24bit/36bit |
Support audio format | DTS-HD/true-HD/LPCM7.1/Dolby-AC3/DTS/DSD |
Date transfer speed | 6.75Gbps |
Input Video signal | 5.0Volts P-P |
Input cable support | <20m AWG24 cable length |
Output cable distance | <20m AWG24 cable length |
Max working current | 300mA |
Power adapter Supply | DC5v |
Power adapter format | Input AC100-240V, output DC5v |
Operating Temperature range | (-15 to +55 Degree) |
Operating Humidity range | 5 to 90%RH (No Condensation) |
Dimension (Lx W x H) | 110x75x23(mm) |
Weight | 219g |
