FEATURES
- 1/3" SONY CMOS
- HD-SDI(1080p, 720p) / High resolution (1000 TV line over)
- HD-SDI(High Definition Serial Digital Interface) / 0 lux at IR on (IR LED 20pcs)
- OSD Controlled / Smart IR / MDIR (Motion Detection IR) / WDR (Wide Dynamic Range)
- DNR (Digital Noise Reduction) / True Day & Night(lCR) / Easy Installation
- Fixed Lens 4.3mm
SPECIFICATIONS
| XDR 222F | |
| Resolution | HD-SDI(1080p, 720p) / 1000 TV line over |
| Sensor | 1/2.9 " SONY CMOS |
| Total Pixels | 2000(H) × 1241(V) = 2.4M Pixel |
| Effective Pixels | 1944(H) × 1092(V) = 2.1M Pixel |
| Scanning System | Progressive |
| S/N (Y signal) | More than 52 dB (AGC Off) |
| Video Output | SMPTE292M (HD-SDI) |
| Min.Illumination | 0 lux at IR on |
| White Balance | Auto / Auto EXT / Pushing / Manual |
| Electronic Shutter Speed | Auto / Manual (1/30sec ~ 1/60,000sec) |
| Brightness | Adjustable (0 ~ 20 Step) |
| SENS_UP | Off / ×2 / ×3 / ×4 |
| DNR | Off / Low / Middle / Hi |
| WDR / BLC | Off / WDR / BLC |
| HLM | Off / Set |
| ACE | Off / On |
| Day & Night | Auto (Day <--> Night time change) , Color , B/W, Extern, MDIR |
| Privacy | Off / On (32 Zone) |
| Motion Detection | Off / On |
| D.ZOOM | 0 ~ ×127 |
| FLIP | Off / On |
| FREEZE | Off / On |
| Language | English |
| Sharpness | Adjustable (0 ~ 10 Step) |
| Mirror | On / Off |
| COMM. | RS-485(PELCO-D) |
| Operating Temperature / Humidity | 14°F~122°F (-10°C~+50°C) / 30%~80% RH |
| Storage Temperature / Humidity | -4°F~+140°F (-20°C~+60°C) / 20%~90% RH |
| Power | DC 12V Only |
| Distance | 300 ~ 450ft (100 ~ 150m) |
| Transmission range | The distant difference is occurred according to cable option and other circumstances (based on RG59: 100rv) |
Products specifications
| Camera Features | Indoor, WDR |
| Resolution | 2MP/1080p |
| Technology | HD-SDI |
| Lens | 4.3mm |
