FEATURES
- 1/3" SONY CMOS
- HD-SDI (1080p, 720p) / High Resolution (1000 TV line over)
- HD-SDI (High Definition Serial Digital Interface) / 1 lux at F1.2 / 0.1 lux (B/W)
- Update Vandalproof & Waterproof Housing (IP68 rating) / OSD Controlled
- Motion / Privacy / Easy Installation / 3 Axis Construction
- DNR (Digital Noise Reduction) / Auto IRIS V/F Lens 2.8~12mm
SPECIFICATIONS
| XVL 202V | |
| Resolution | HD-SDI(1080P, 720P) / 1000 TV Line Over |
| Sensor | 1/3“ SONY CMOS |
| Total Pixels | 2010(H) X 1108(V) = 2.2M Pixel |
| Effective Pixels | 1944(H) X 1092(V) = 2.1M Pixel |
| Scanning System | Progressive Scan |
| S/N (Y Signal) | More than 52 dB(AGC Off) |
| Video Output | SMPTE292M (HD-SDI) / CVBS : 1.0Vp-p (75Ω) |
| Min. Illumination | 1 Lux at F1.2 / 0.1 Lux (B/W) |
| White Balance | AUTO / AUTO EXT / PUSHING / MANUAL |
| Electronic Shutter Speed | AUTO / MANUAL(1/30sec ~ 1/30,000sec) |
| Brightness | Adjustable (0~20 Step) |
| Sens-up | OFF / ×2 / ×3 / ×4 |
| DNR | OFF / LOW / MIDDLE / HI |
| WDR / BLC | OFF / Single scan WDR / BLC |
| HLM | OFF / SET |
| ACE | OFF / ON |
| Day & Night | AUTO (Day <-> Night TIME Change), COLOR, B/W |
| Privacy | OFF / ON (28 Zone) |
| Motion Detection | OFF / ON |
| D. Zoom | 0 ~ ×112 |
| FLIP | OFF / ON |
| FREEZE | OFF / ON |
| Language | ENGLISH |
| Sharpness | ADJUSTABLE (0~10 STEP) |
| Mirror | ON / OFF |
| COMM. | RS-485(PELCO-D) |
| Operating Temperature / Humidity | -10°C~+50°C (14°F ~ 122°F) / 30% ~ 80% RH |
| Storage Temperature / Humidity | -20°C~+60°C (-4°F ~ +140°F) / 20% ~ 90% RH |
| Power | DC 12V |
| HD-SDI | 300 ~ 450ft (100 ~ 150m) |
| Transmission range | Max transmission range is depends on the cable manufacturer and the installtion environment. |
Products specifications
| Camera Features | Vandal Proof, WDR |
| Resolution | 2MP/1080p |
| Technology | HD-SDI |
| Lens | 2.8-12mm |
