Key Features
- Standard H.264 Compression Format
- Embedded high-speed microcontroller & Linux system, high stability, auto system upgrading
- Support Time, Motion, and Alarm searching mode
- Support mouse, IR remote control, and Front panel
- Support network remote, USB backup
- Pentaplex, 16channel playback simultaneously
- Recording bit/frame adjustable
- Central Management System
- Support live display, record, playback, backup, and network
- Supports 3G, GPRS, WIFI wireless of mobile phone network monitoring function (phone monitoring, capture, PTZ control)
- Built-in VGA interface, output resolution up to 1024*768
- More interface; support USB, alarm, intercom, PTZ control
- Easy & Free Upgrade
SPECIFICATIONS
| DVST-SD-16 | |
| Video Compression | H.264® CODEC |
| Video Input | BNC*16 (Composite signal 1.0Vp-p 75Ω) |
| Output (BNC) | BNC*1 (Composite signal 1.0Vp-p 75Ω) |
| Output (VGA) | Built-in VGA interface (1280*1024, 1024*768, 800*600) |
| Video Record Frame Rate | NTSC : 30fps/ch |
| Recording Resolution | NTSC : 360*240 480fps |
| Operation Mode | Live display, Record, Playback, Backup, Network |
| Recording Mode | Manual, Time, Motion, Remote |
| Audio Input/Output | 4ch(RCA)/1ch(RCA) |
| Audio encode/decode | ADPCM |
| PTZ Camera Control | YES(Pelco-D&Pelco-P) |
| HDD Storage | 1pc SATA HDD |
| Network Interface | RJ45(10M/100M adjustable) |
| Network protocol | TCP/IP, UDP, HTTP, NTP, DHCP, DDNS |
| CMS | YES(Maximum:16 different IP addresses) |
| IR Remote Control | YES |
| Multilingual OSD | YES |
| Voltage input | 12V |
Products specifications
| Number of Channels | 16Ch |
| Technology | Analog |
