| Product Highlights | |
| Resolution | 4K 8MP |
| Camera Features | Outdoor |
| Lens | 2.8mm |
| Technology | HD-TVI |
- 8.29 MP high performance CMOS
- 3840 × 2160 resolution
- 2.8 mm fixed lens
- Matrix IR 2.0, smart IR, up to 98ft(30 m) IR distance
- 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
- DWDR, DNR
- IP67
- OSD Menu via UTC technology with Platinum DVR
| CAMERA | |
| Image Sensor | 8.29 megapixel progressive scan CMOS |
| Signal System | NTSC/PAL |
| Frame Rate | TVI: [email protected], 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps CVI: [email protected], 8MP@15fps AHD: 5MP@20fps CVBS: 960H P/N |
| Min. Illumination | Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Lens | 2.8 mm fixed lens |
| Shutter Speed | PAL: 1/12.5 s to 1/50,000 s NTSC: 1/15 s to 1/50,000 s |
| Day & Night | ICR cut filter |
| Synchronization | Internal |
| Resolution | 3840 (H) × 2160 (V) |
| Angle Adjustment (Bracket) | Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360° |
| Lens Mount | M16 |
| DWDR (Digital Wide Dynamic) | 105 dB |
| MENU | |
| AGC | Yes |
| D/N Mode | Color/ BW/ Auto |
| White Balance | Auto/Manual |
| Language | English |
| BLC | Yes |
| Function | Brightness,Sharpness,Digital noise reduction, Mirror, Smart IR |
| GENERAL | |
| Working Temperature /Humidity | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ±25% |
| Power Consumption | Max. 5.3 W |
| Weather Proof Ratings | IP67 |
| IR Range | Up to 98ft (30m) |
| Dimensions | 90 mm × 79.37 mm (3.54" × 3.12" ) |
| Weight | Approx. 310 g (0.68 lb.) |
