- 1/3" Sensor
- HD 1080P Video Output
- Adopts HDTVI Technology
- True Day/Night
- 3.6mm Fixed Lens
- 24 IR LEDs up to 65ft (20m)
- WDR
- OSD Menu via UTC technology with Platinum TVI DVR
- DC 12V
CMHR6222W | |
Camera | |
Image Sensor | 1/3"Sensor |
Signal System | NTSC / PAL(Euro Version) |
Effective Pixels | 1920(H)×1080(V) |
Min. Illumination | 0.01 Lux @ (AGC ON),0 Lux with IR |
Shutter Speed | NTSC: 1/30 ~ 1/50,000 PAL: 1/25 ~ 1/50,000 |
Lens | 3.6mm |
Day & Night | ICR |
Synchronization | Internal synchronization |
Video Frame Rate | NTSC:1080p@30fps/PAL:1080p@25fps |
HD Video Output | 1 Analog HD output |
S/N Ratio | More than 52dB |
Menu | |
Scene | Indoor, Outdoor, Indoor1, LOW-LIGHT |
Camera ID | On / off (15 characters, position programmable) |
AGC | Support |
D / N Mode | Color / BW / EXT |
White Balance | ATW, AWC-SET, Indoor, Outdoor, Manual |
D/N Mode | Color/BW/SMART IR |
Privacy Mask | On/Off,maximum 8 zones |
Motion Detection | On / Off, maximum 4 zones |
BLC | Support |
Anti-flicker | On / off |
Language | English, Japanese, CHN1, CHN2, Korean, German, French, Italian,Spanish,Polish, Russian, Portuguese, Dutch, Turkish, Hebrew and Arabic |
Functions | Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
General | |
Working Temperature /Humidity |
-4°F - 140°F(-20 °C - 60 °C ) |
Humidity 90% or less (non-condensing) | |
Power Supply | 12V DC |
Power Consumption | Max.4W |
Weather Proof Ratings | IP66 |
IR Range | Up to 65ft(20m) |
Dimension | φ2.8'' × 5.9'' ( φ70 x 149.5mm) |
Weight | 0.8lb(360g) |
Products specifications
Resolution | 2MP/1080p |
Camera Features | WDR, Outdoor |
Lens | 3.6mm |
Technology | HD-TVI |
