CMHR8422W |
Camera |
Image Sensor |
1/3"Sensor |
Signal System |
NTSC / PAL(Euro Version) |
Effective Pixels |
1920(H)×1080(V) |
Min. Illumination |
0.01 Lux @ (AGC ON),0 Lux with IR |
Shutter Speed |
NTSC: 1/30 ~ 1/50,000 PAL: 1/25 ~ 1/50,000 |
Lens |
3.6mm |
Day & Night |
ICR |
Synchronization |
Internal synchronization |
Video Frame Rate |
NTSC:1080p@30fps/PAL:1080p@25fps |
HD Video Output |
1 Analog HD output |
S/N Ratio |
More than 52dB |
Menu |
|
Scene |
Indoor, Outdoor, Indoor1, LOW-LIGHT |
Camera ID |
On / off (15 characters, position programmable) |
AGC |
Support |
D / N Mode |
Color / BW / EXT |
White Balance |
ATW, AWC-SET, Indoor, Outdoor, Manual |
D/N Mode |
Color/BW/SMART IR |
Privacy Mask |
On/Off,maximum 8 zones |
Motion Detection |
On / Off, maximum 4 zones |
BLC |
Support |
Anti-flicker |
On / off |
Language |
English, Japanese, CHN1, CHN2, Korean, German, French, Italian,Spanish,Polish, Russian, Portuguese, Dutch, Turkish, Hebrew and Arabic |
Functions |
Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
General |
Working Temperature /Humidity |
-4°F - 140°F(-20 °C - 60 °C ) |
Humidity 90% or less (non-condensing) |
Power Supply |
12V DC |
Power Consumption |
Max.5W |
Weather Proof Ratings |
IP66 |
IR Range |
Up to 131ft(40m) |
Dimension |
φ3.7'' × 3.3''× 8.3'' ( 94.6 x 83 x 210.8mm) |
Weight |
1.6lb(700g) |
