System | Model | VT-N5008 |
Operating system | Embedded LINUX operating system | |
System resource | Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. | |
Interface | Operation interface | 16bit real color GUI interface support mouse operation |
Display screen | 1/4 screen (take analog channel as an example, other is base on the selected channel mode) | |
Video | ||
Image encode | H.264(Main Profile) | |
Monitor quality | Monitor:D1;VGA、HDMI:High definition(Max 1920*1080) | |
Playback quality | 1080P/720P/960H/D1/HD1/CIF/QCIF | |
Network digital input: | 8*1080P | |
8*720P | ||
16* D1 | ||
Motion detection | Each channel can set 396(22*18)detection area;can set multi-level of flexibility (for local analog channel only) | |
Audio | Audio compression | G711A |
Bidirectional talk | support | |
Record and playback | Record mode | manual>alarm>motion detection>timing |
Local playback | 1 road and playback, | |
Video search | time、date、event、channel search | |
Storage and back up | Space occupation | Video:CIF 4~5G/day*channel, D1 16~20G/day*channel,960H 24~30G/day*channel;720P 40~50 G/ day*channel,1080P 80~100G/ day*channel;audio:691.2M/day*channel |
Video storage | Local HDD 、Network | |
Back up mode | Network backup、USB portable HDD、USB imprint、SATA imprint | |
Interface | Video input | None BNC |
Video output | 2ch BNC (1.0Vp-p,75Ω)( including 1ch Spot output),1ch VGA,1ch HDMI | |
Audio input | 1ch RCA(200-2800mV,30KΩ) | |
Audio input | 1ch RCA(200-3000mV,5KΩ) | |
Network port | RJ45 10M/100M self-adaptive Ethernet port | |
PTZ control | 1RS485;support multi kinds of PTZ protocol | |
USB port | 2*USB2.0(one of them is multiplexing with what at the back panel) | |
HDD port | 1SATA ports(each max to3TB) | |
Wireless port | 3G、WIFI(extension via USB port) | |
Onvif | support | |
Other | Power | 12V/3A |
Dimension | 8.8"(L)* 8.8"(W)* 1.7"(H) |
Products specifications
Number of Channels | 8Ch |
Technology | IP/Network |
