- New, logical, and visual GUI design
- Dual-OS design to ensure high reliability
- ANR technology to enhance storage reliability if the network gets interrupted
- N+1 hot spare system
- Streaming over TLS encryption technology (enhanced SDK service and RTP over HTTPS protocol) provides more secure transmission service (up to 128 Mbps outgoing TLS stream bandwidth (when RAID is enabled, it will restrict TLS stream outgoing bandwidth to 64 Mbps)
- Up to 64 cameras can be connected (up to 12 MP)
- Connectable to the third-party network cameras
- H.265+ compression effectively reduces the storage space by up to 75%
- Full channel recording at up to 12 MP resolution
- HDMI1 / VGA1 and HDMI2 / VGA2 outputs provided
- HDMI1 video output at up to 4K (3840 × 2160) resolution
- Up to 8 x SATA interfaces and 1 x eSATA interface for HDD connections
- 10 TB capacity for each HDD
- 16 channels of synchronous playback at up to 1080p resolution
- Important file management
- HDD health monitoring
- Supports multiple VCA (Video Content Analytics) events
- Smart search for the selected area in the video; smart playback to improve efficiency
- Supports VCA search for fires / vessels / temperature differences; detection-triggered video files
- POS information overlay on live view and playback
- POS-triggered recording and alarm
- LTS-Connect for easy network management
- 2 x Gigabit Ethernet network interfaces
|
Video / Audio Input |
IP video input |
64 channels |
|
Up to 12 MP resolution |
||
|
Two-way audio |
1 ch, RCA (2.0 Vp-p, 1 k Ω) |
|
|
Network |
Incoming bandwidth |
320 Mbps or 200 Mbps (when RAID is enabled) |
|
Outgoing bandwidth |
256 Mbps, or 200 Mbps (when RAID is enabled) |
|
|
Remote connections |
128 |
|
|
Video / Audio Output |
Recording resolutions |
3, 4, 5, 6, 8, 12 MP; 1080p; UXGA; 720p; VGA; |
|
CVBS output (optional) |
1 ch, BNC (1.0 Vp-p, 75 Ω), resolutions: PAL: 704 × 576, NTSC: 704 × 480 |
|
|
VGA 1 / HDMI 1 output resolutions |
HDMI 1: 4K (3840 × 2160) / 60 Hz, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
|
VGA 1: 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
||
|
VGA 2 / HDMI 2 output resolutions |
1920 × 1080p / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
|
Audio output |
2 ch, RCA (2.0Vp-p, 1 KΩ) |
|
|
Decoding |
Decoding formats |
H.264 / H.264+ / H.265 / H.265+ / MPEG4 |
|
Live view / playback resolution |
3, 4, 5, 6, 8, 12 MP; 1080p; UXGA; 720p; VGA; |
|
|
Synchronous playback |
16 ch |
|
|
Capability |
2 ch @ 12 MP (20 fps) / 4 ch @ 8 MP (25 fps) / 8 ch @ 4 MP (30 fps) / 16 ch @ 1080p (30 fps) |
|
|
Network Management |
Network protocols |
TCP/IP, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
|
Hard Drives |
SATA |
8 x SATA interfaces for up to 8 x HDDs |
|
eSATA |
1 x eSATA interface |
|
|
Capacity |
Up to 10 TB capacity for each HDD |
|
|
Disk Array |
Array type |
RAID 0 / 1 / 5 / 6 / 10 |
|
Number of arrays |
4 |
|
|
External Interface |
Network interface |
2 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
|
Serial interface |
RS-232; RS-485; Keyboard |
|
|
USB interface |
Front panel: 2 x USB 2.0 |
|
|
Alarm channels (in/out) |
16 / 4 |
|
|
General |
Power supply |
100 to 240V AC, 50 to 60 Hz |
|
Max. power |
200 W |
|
|
Consumption (without HDD) |
≤ 30 W |
|
|
Operating temperature |
14° to 131° F (-10° to 55° C) |
|
|
Operating humidity |
10 to 90 % |
|
|
Dimensions |
17.5 × 18.5 × 3.5" (445 × 470 ×90 mm) |
|
|
Weight (without HDD) |
≤ 17.6 lb (8 kg) |
| Technology | IP/Network |
| Number of Channels | 64Ch, 4Ch |
