- New, visualized, and more logical GUI design
- Dual-OS design improves reliability
- ANR technology enhances storage reliability if network gets disconnected
- Streaming over TLS encryption technology (enhanced SDK service and RTP over HTTPS protocol) provides a more secure transmission (up to 128 Mbps TLS stream outgoing bandwidth)
- Up to 32 IP cameras can be connected (up to 12 MP each)
- Compatible with third-party network cameras
- H.265+ compression effectively reduces storage usage by up to 75%
- Full channel recording at up to 12 MP resolution
- HDMI Video output at up to 4K (3840 x 2160) resolution
- High quality with clear, sharp imaging
- Up to 4 x SATA interfaces for HDD connections
- 16 channels of synchronous playback at up to 1080p resolution
- File management
- HDD health monitoring
- Supports multiple Video Content Analytics (VCA) events
- Smart search for the selected area in the video, and smart playback to improve the efficiency
- Supports VCA search for fires / vehicles / temperature differences; detection-triggered video files
- POS information overlay on live view and playback
- POS-triggered recording and alarm
- LTS-Connect for easy network management
- Gigabit Ethernet network interface
- 24 independent PoE network interfaces are provided
|
Audio / Video Input |
IP video input |
32 channels |
|
Up to 12 MP resolution |
||
|
Two-way audio |
1 channel, RCA (2.0 Vp-p, 1 k Ω) |
|
|
Network |
Incoming bandwidth |
320 Mbps |
|
Outgoing bandwidth |
256 Mbps |
|
|
Remote connections |
128 |
|
|
Audio / Video Output |
Recording resolution |
12 / 8 / 6 / 5 / 4 / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
|
CVBS output |
1 ch, BNC (1.0 Vp-p, 75 Ω) |
|
|
HDMI1 / VGA1 output resolution |
HDMI1: 4K (3840 × 2160) / 60 Hz, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
|
VGA1: 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
||
|
HDMI2 output resolution |
1920 × 1080p / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
|
Audio output |
1 ch, RCA (Linear, 1 kΩ) |
|
|
Decoding |
Decoding formats |
H.265+ / H.265 / H.264+ / H.264 / MPEG4 |
|
Live view / playback resolution |
12 / 8 / 6 / 5 / 4 / 3 / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
|
|
Synchronous playback |
16 channels |
|
|
Capacity |
2 ch @ 12 MP (20 fps) / 4 ch @ 8 MP (30 fps) / 8 ch @ 4 MP (30 fps) / |
|
|
Network Management |
Network protocols |
TCP/IP, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, SNMP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
|
Hard Drive Interface |
SATA |
4 x SATA interfaces for 4 x HDDs |
|
Capacity |
Up to 8 TB capacity for each HDD |
|
|
eSATA |
1 x eSATA interface |
|
|
External interface |
Network interface |
1 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
|
Serial interface |
1 x RS-485 (half-duplex), 1 x RS-232 |
|
|
USB interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
|
|
Alarm channels (in / out) |
16 / 4 (Optonal: 16/8) |
|
|
POE Interface |
Interface |
24 x RJ-45 10/100 Mbps self-adaptive Ethernet interfaces |
|
Power |
≤ 210 W |
|
|
Supported standard |
IEEE 802.3 af / at |
|
|
General |
Power supply |
100 to 240V AC |
|
Total power |
≤ 360 W |
|
|
Power consumption (without HDD or PoE) |
≤ 20 W |
|
|
Operating temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
|
|
Operating humidity |
10 to 90 % |
|
|
Dimensions |
17.5 × 15.7 × 2.8" (445 × 400 × 71 mm) |
|
|
Weight (without HDD) |
≤ 5 kg (11 lb) |
| Technology | IP/Network |
| Number of Channels | 32Ch |
