| Product Highlights | |
| Technology | IP/Network |
| Number of Channels | 16Ch |
- H.265+ compression effectively reduces storage use by up to 75%
- Dual-stream recording uses bandwidth more effectively
- Streaming over TLS encryption technology provides more secure transmission
- Supports double verification for playback and downloading
- Independent HDMI and VGA outputs
- HDMI video output at up to 8K resolution
- Dual 4K HDMI output resolution
- Up to 4 x SATA interfaces for HDD connection
- 16 channels of synchronous playback
- Supports multiple Video Content Analytics (VCA) events
- Special camera smart functions can be configured, such as VCA detections (motion, line crossing, intrusion, etc.), heat mapping, LPR, etc.
- POS information overlay on live view and playback; POS-triggered recording and alarms
- 16 independent PoE network interfaces
- Single self-adaptive 10/100/1000 Mbps Ethernet interface
- PT Cloud & DDNS for easy network management
- Smooth streaming technology
- Supports web access without extra plug-ins
| Video and Audio | |
| IP Video Input | 16 channels, up to 32 MP resolution |
| Incoming Bandwidth | 256 Mbps |
| Outgoing Bandwidth | 256 Mbps |
| HDMI 1 Output | 8K : 7680x4320 / 30 Hz 4K : 3840 x 2160 / 60 Hz; 3840 x 2160 / 30 Hz 2K : 2560 x 1440, 1920 × 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, or 1024 x 768 / 60 Hz |
| HDMI 2 Output | 4K : 3840 x 2160 / 60 Hz, 3840 x 2160 / 30 Hz 2K : 2560 x 1440, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 x 720, or 1024 x 768 / 60 Hz |
| VGA Output | 1920x1080, 1600 x 1200, 1280 x 1024, 1280 x 720, or 1024 x 768 / 60 Hz |
| Video Output Mode | HDMI1/VGA simultaneous output, HDMI2 / VGA independent output |
| CVBS Output | 1 ch, BNC (1.0 Vp-p, 75 2), resolution : PAL : 704 × 576, NTSC : 704 × 480 |
| Audio Output | 1 ch, RCA (Linear, 1 KQ) |
| Two-Way Audio | 1 ch, RCA (2.0 Vp-p, 1 KQ, using the audio input) |
| Decoding | |
| Decoding Format | H.265+/H.265/H.264+ / H.264 |
| Recording Resolution | 3, 4, 5, 6, 8, 12, 24, 32 MP / 1080p / UXGA / 720p/VGA / 4CIF / DCIF / 2CIF/CIF / QCIF |
| Synchronous Playback | 16-channel |
| Decoding Capability | 8 ch @ 8 MP (25 fps) / 16 ch @ 4 MP (30 fps) |
| Dual-Stream Recording | Supported |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711 ulaw/G.711 alaw / G.722 / G.726 / AAC / MP2L2 |
| Network | |
| Remote Connections | 128 |
| Network Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, ISCSI, ISUP, UPnP™M, HTTP, HTTPS |
| Network Interface | 1 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| PoE | |
| Interface | 16 x RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power | ≤ 200 W |
| Standard | IEEE 802.3 af at |
| RAID | |
| RAID Type | N/A |
| Auxiliary Interface | |
| eSATA | 1 x eSATA interface |
| SATA | 4 x SATA interfaces |
| Capacity | Up to 14 TB capacity for each disk |
| Serial Interface | 2 x RS-485 (half-duplex), 1 RS-232 |
| Alarm In / Out | 16/9 |
| USB Interface | Front panel : 2 × USB 2.0; Rear panel : 1 x USB 3.0 |
| Ctrl 12V | Controllable 12 VDC, 1 A power output for external alarm device; power will be turned on when the alarm output is triggered Note : The Ctrl 12V power is controlled by alarm output 9 |
| 12 VDC | 12 VDC, 1 A power output |
| General | |
| Power Supply | 100 to 240 VAC, 50 to 60 Hz |
| Consumption | ≤ 15 W (without HDD and PoE off) |
| Operating Temperature | 14° to 131° F (-10° to 55° C) |
| Operating Humidity | 10 to 90% |
| Chassis | 19-inch rack-mounted 1.5U chassis |
| Dimensions (W x D x H) | 17.5 x 15.7 x 3.0 in. (445 x 400 x 75 mm) |
| Weight (without HDD) | ≤11 lbs (5 kg) |
| Certifications | |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 |
| CE D | EN 55032 : 2015+A1 : 2020, ENIEC61000-3-2 : 2019+A1 : 2021, EN 61000-3-3 : 2013+A1 : 201 9, EN 50130-4 : 2011+A1 : 2014, EN 55035 : 2017+A11 : 2020 |
