- Supports H.265 / H.265 Pro / H.265 Pro+ video compression
- Supports HD-TVI / AHD / CVI / CVBS / IP video input
- Up to 40 IP camera inputs (up to 6 MP)
- Up to 2,625 ft (800 m) for 1080p and 3,900 ft (1,200 m) for 720p HD-TVI signal
- Up to 10 TB capacity per HDD
- Supports POS-triggered recording and POS information overlay
|
Recording |
||
|
Video compression |
H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ |
|
|
Encoding resolution |
1080p Lite mode disabled: 4 MP lite / 3 MP / 1080p / 1080p lite / 720p / WD1 / 4CIF / VGA / CIF 1080p Lite mode enabled: 4 MP lite / 3 MP / 1080p lite / 720p / 720p lite / WD1 / 4CIF / VGA / CIF |
|
|
Frame rates |
Main stream, 1080p Lite mode disabled: 4 MP stream access: 4 MP lite @ 15 fps; 1080p lite / 720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) 3 MP stream access: 3 MP / 1080p / 720p / WD1 / 4CIF / VGA / CIF @ 15 fps 1080p stream access: 1080p / 720p @ 15 fps; WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) 720p stream access: 720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) Main stream, 1080p Lite mode enabled: For 4 MP stream access: 4 MP lite @ 15 fps; 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) 3 MP stream access: 3 MP / 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF @ 15 fps 1080p stream access: 1080p lite / 720p lite / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30fps (N) 720p stream access: 720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) |
|
|
Sub-stream: WD1 / 4CIF @ 12 fps; CIF @ 25 fps (P) / 30 fps (N) |
||
|
Video bit rate |
32 Kbps to 6 Mbps |
|
|
Dual stream |
Supported |
|
|
Stream type |
Video, Video & Audio |
|
|
Audio compression |
G.711u |
|
|
Audio bit rate |
64 Kbps |
|
|
Video and Audio |
||
|
IP video input |
16 chs (up to 40) |
16 chs (up to 48) |
|
Up to 6 MP resolution |
||
|
Supports H.264 / H.264+ / H.265 / H.265+ IP cameras |
||
|
Analog video input |
24 chs |
32 chs |
|
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
||
|
HDTVI input |
4 MP, 3 MP, 1080p @ 25 fps, 1080p @ 30 fps; 720p @ 25, 30, 50, 60 fps *: The 3 MP signal input is only available for channels 1 - 4. |
|
|
AHD input |
4 MP, 1080p @ 25 fps, 1080p @ 30 fps, 720p @ 25 fps, 720p @ 30 fps |
|
|
HDCVI input |
1080p @ 25, 30 fps; 720p @ 25, 30 fps |
|
|
CVBS input |
PAL / NTSC |
|
|
CVBS output |
1 ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
|
|
HDMI1 / VGA output |
1 ch, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, |
|
|
HDMI2 output |
1 ch, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
|
Audio input |
4 ch, RCA (2.0 Vp-p, 1 KΩ) |
|
Audio output |
1 ch, RCA (Linear, 1 KΩ) |
|
Two-way audio |
1 ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
|
Synchronous playback |
16 ch |
|
Network |
|
|
Remote connections |
128 |
|
Network protocols |
TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP |
|
Network interface |
1 x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
|
Auxiliary interface |
|
|
SATA |
4 x SATA interfaces |
|
eSATA |
Supported |
|
Capacity |
Up to 10 TB capacity for each disk |
|
Serial interface |
RS-232, RS-485 (full-duplex), Keyboard |
|
Alarm in/out |
16 / 4 |
|
USB interface |
Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
|
General |
|
|
Power supply |
100 to 240 V AC, 50 to 60 Hz, 1.1 A |
|
Power Consumption |
≤ 45 W |
|
Operating temperature |
14° to 131° F (-10° to 55° C) |
|
Operating humidity |
10% to 90% |
|
Dimensions (W × D × H) |
17.3 × 15.4 × 2.8 in. (440 × 390 × 70 mm) |
|
Weights (without HDD) |
≤ 15.4 lb (7 kg) |
