| VIDEO/AUDIO INPUT | |
| Video Compression | H.264 Zip+/ H.264 |
| Video Input | 16ch BNC (1.0 Vp-p, 75Ω), PAL/NTSC self-adaptive |
| IP Input | 2ch (Support ONVIF, up to 2MP resolution) |
| Audio Compression | G.711u |
| Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Two-Way Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| VIDEO/AUDIO OUTUPUT | |
| HDMI Output | 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz |
| VGA Output | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Frame Rate | Main stream: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF (1/16fps to real time frame rate) Sub-stream:WD1/4CIF/2CIF@12fps;CIF/QVGA/QCIF@real time frame rate |
| Video Bit Rate | 32 Kbps- 6 Mbps |
| Audio Output | 1-ch, RCA (Linear, 1 kΩ) |
| Audio Bit Rate | 64 Kbps |
| Dual Stream | Support |
| Stream Type | Video, Video & Audio |
| Synchronous Playback | 16ch |
| NETWORK | |
| Remote Connections | 128 |
| Network Protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iS CSI, UPnP™, HTTPS, PT Cloud |
| HARD DISK | |
| SATA | 2 SATA |
| Capacity | Up to 8TB HDD capacity for each disk |
| EXTERNAL INTERFACE | |
| Network interface | 1:10M / 100M / 1000M self-adaptive Ethernet interface |
| Serial interface | RS-485 |
| USB Port | 1 X USB2.0, 1 X USB3.0 |
| Alarm In/Out | 16/4 |
| GENERAL | |
| Power supply | DC12V |
| Consumption | ≤ 30W |
| Working temperature | -10 ° C ~ + 55 ° C(14° F -131° F) |
| Working humidity | 10% ~ 90% |
| Chassis | 1U Chassis |
| Dimensions (WxDxH) | 440 × 290 × 45 mm (17.3 × 11.4 × 1.8 inch) |
| Weight | ≤2Kg (4.4lb) |
