| Product Highlights | |
| Number of Channels | 16Ch |
| Technology | HD-TVI |
- Deep learning-based motion detection 2.0 for all analog channels
- H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ video compression
- HD-TVI / AHD / CVI / CVBS / IP video inputs
- Audio via coaxial cable
- Up to 24 IP camera input channels (up to 6 MP)
- Up to 10 TB capacity per HDD
| Motion Detection 2.0 | |
| Person / Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify humans and vehicles and vastly reduce false alarms caused by objects like leaves and lights. Quick search by object or event type is supported |
| Perimeter Protection | |
| Person / Vehicle Analysis | Up to 4 channels |
| Face Detection | |
| Face Detection and Capture | 1 channel of human face capture (HD analog camera) |
| Recording | |
| Video Compressions | H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ |
Encoding Resolutions | Main stream, 1080p Lite mode disnabled: For 4 MP stream access: 4 MP lite @ 15 fps; 1080p lite / 720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) For 3 MP stream access: 3 MP / 1080p / 720p / VGA / WD1 / 4CIF / CIF @ 15 fps For 1080p stream access: 1080p / 720p @ 15 fps; VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) For 720p stream access: 720p / VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) When 1080p Lite mode enabled: 4 MP lite / 3 MP @ 15 fps; 1080p lite / 720p lite / VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) Sub-stream: WD1 / 4CIF @ 12 fps; CIF @ 25 fps (P) / 30 fps (N) |
| Video Bitrate | 32 Kbps to 6 Mbps |
| Dual Stream | Supported |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711 u |
| Audio Bitrate | 64 Kbps |
| Video and Audio | |
| IP Video Input | 2 channels (up to 18 ch) Enhanced IP mode on: 8-ch (up to 24-ch), each up to 4 Mbps Up to 6 MP resolution Supports H.264 / H.264+ / H.265 / H.265+ IP cameras |
| Analog Video Input | 16 ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HD-TVI Input | 3, 4 MP; 1080p @ 25 / 30 fps; 720p @ 25 / 30 / 50 / 60 fps The 3 MP signal input is only available for channels 1/2/3/4 of LTD8316M-ET |
| AHD Input | 4 MP, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps |
| HD-CVI Input | 4 MP, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps |
| CVBS Input | PAL / NTSC |
| CVBS Output | 1 ch, BNC (1.0 Vp-p, 75 Ω) Resolutions: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI / VGA Output | 1 ch, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz, HDMI / VGA simultaneous output |
| Audio Input | 1 ch, RCA (2.0 Vp-p, 1 kΩ) 16 ch via coaxial cable |
| Audio Output | 1 ch, RCA (Linear, 1 kΩ) |
| Two-Way Audio | 1 ch, RCA (2.0 Vp-p, 1 kΩ) (using the first audio input) |
| Synchronous Playback | 16 ch |
| Network | |
| Remote Connections | 128 |
| Network Protocols | TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network Interface | 1 x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Wi-Fi | Compatible with Wi-Fi networks using dongle through USB interface |
| Auxiliary Interfaces | |
| SATA | 2 x SATA interfaces, up to 10 TB capacity for each drive |
| Serial | RS-485 (half-duplex) |
| USB | Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0 |
| Alarm Chanels (In/Out) | N/A |
| General | |
| Power Supply | 12 VDC, 3.3 A |
| Consumption (without HDD) | ≤ 40 W |
| Operating Temperature | 14° to 131° F (-10° to 55° C) |
| Operating Humidity | 10 to 90% |
| Dimensions (W × D × H) | 15.0 × 12.6 × 1.9" (380 × 320 × 48 mm) |
| Weight (without HDD) | ≤ 4.4 lb (2 kg) |
