- Deep learning-based motion detection 2.0 for all analog channels
- H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ video compression
- HD-TVI / AHD / CVI / CVBS / IP video inputs
- Audio via coaxial cable
- Up to 12-ch IP camera inputs (up to 6 MP)
- Up to 10 TB capacity per HDD
| Motion Detection 2.0 | |
| Person / Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and vastly reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; |
| Perimeter Protection | |
| Person / Vehicle Analysis | Up to 4 channels |
| Face Detection | |
| Face Detection and Capture | 1 ch. of human face capture (HD analog camera) |
| Recording | |
| Video Compression | H.264 / H.264+ / H.265 / H.265 Pro / H.265 Pro+ |
Encoding Resolutions |
Main stream, 1080p lite mode disnabled: For 4 MP stream access: 4 MP lite @ 15 fps; 1080p lite / 720p / WD1 / 4CIF / VGA / CIF @ 25 fps (P) / 30 fps (N) For 3 MP stream access: 3 MP / 1080p / 720p / VGA / WD1 / 4CIF / CIF @ 15 fps For 1080p stream access: 1080p / 720p @ 15 fps; VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) For 720p stream access: 720p / VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) When 1080p Lite mode enabled: 4 MP lite / 3 MP @ 15 fps; 1080p lite / 720p lite / VGA / WD1 / 4CIF / CIF @ 25 fps (P) / 30 fps (N) Sub-stream: WD1 / 4CIF @ 12 fps; CIF @ 25 fps (P) / 30 fps (N) |
| Video Bitrate | 32 Kbps to 6 Mbps |
| Dual Stream | Supported |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711 u |
| Audio Bitrate | 64 Kbps |
| Video and Audio | |
| IP Video Input | 2 channels (up to 10 ch) Enhanced IP mode on: 4 channels (up to 12 ch), each up to 4 Mbps Up to 6 MP resolution Supports H.264 / H.264+ / H.265 / H.265+ IP cameras |
| Analog Video Input | 8 channels BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HD-TVI Input | 3, 4 MP, 1080p @ 25 / 30 fps, 720p @ 25 / 30 / 50 / 60 fps 3 MP signal input only available for channel 1 on LTD8304M-ET, channels 1 or 2 of LTD8308M-ETC |
| AHD Input | 4 MP, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps |
| HD-CVI Input | 4 MP, 1080p @ 25 / 30 fps, 720p @ 25 / 30 fps |
| CVBS Input | PAL / NTSC |
| CVBS Output | 1 ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI / VGA Output | 1 ch, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz, HDMI / VGA simultaneous output |
| Audio Input | 1 ch, RCA (2.0 Vp-p, 1 KΩ) 8 ch via coaxial cable |
| Audio Output | 1 ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1 ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Synchronous Playback | 8 channels |
| Network | |
| Remote Connections | 64 |
| Network Protocols | TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network Interface | 1 x RJ45 10/100 Mbps self-adaptive Ethernet interface |
| Wi-Fi | Compatible with Wi-Fi network using dongle through USB interface |
| Auxiliary Interface | |
| SATA | 1 x SATA interface, up to 10 TB capacity for each disk |
| Serial | RS-485 (half-duplex) |
| USB | Front panel: 1 x USB 2.0; Rear panel: 1 x USB 2.0 |
| Alarm Channels (In/Out) | N/A |
| General | |
| Power Supply | 12 VDC, 1.5 A |
| Consumption (without HDD) | ≤ 18 W |
| Operating Temperature | 14° to 131° F (-10° to 55° C) |
| Operating Humidity | 10% to 90% |
| Dimensions (W × D × H) |
12.4 × 9.5 × 1.8" (315 × 242 × 45 mm) |
| Weight (without HDD) |
≤ 3.9 lb (1.78 kg) |
