| Product Highlights | |
| Technology | HD-TVI |
| VIDEO/AUDIO INPUT | |
| Video Compression | H.264 Zip+/ H.264 |
| Video Input | 4ch BNC (1.0 Vp-p, 75Ω), PAL NTSC self-adaptive |
| IP Input | 1ch (Support ONVIF, up to 2MP resolution) |
| Audio Compression | G.711u |
| Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Two-Way Audio Input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| VIDEO/AUDIO OUTUPUT | |
| HDMI/VGA Output | 1920 x 1080 |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 1 kΩ) |
| Frame Rate | Main stream:1/16 fps to real time frame rate Sub-stream: WD1/4CIF@12fps,CIF/QVGA/QCIF@real time frame rate |
| Video Bit Rate | 32 Kbps-6Mbps |
| Audio Output | 1-ch, RCA (Linear, 1 kΩ) |
| Audio Bit Rate | 64 Kbps |
| Dual Stream | Support |
| Stream Type | Video, Video & Audio |
| Synchronous Playback | 4ch |
| NETWORK | |
| Remote Connections | 128 |
| Network Protocols | TCP/IP, PPPoE, DHCP, PT Cloud P2P, DNS, DDNS, NTP, SAD P, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| HARD DISK | |
| SATA | 1 SATA |
| Capacity | Up to 8TB HDD |
| EXTERNAL INTERFACE | |
| Network interface | 1:10M / 100M self-adaptive Ethernet interface |
| Serial interface | RS-485 |
| USB Port | 2 X USB2.0 |
| Alarm In/Out | 4/1 |
| GENERAL | |
| Power supply | DC12V |
| Consumption | ≤ 15W |
| Working temperature | -10 ° C ~ + 55 ° C(14° F -131° F) |
| Working humidity | 10% ~ 90% |
| Chassis | Compact 1U Chassis |
| Dimensions (WxDxH) | 315 X 230 X 45 mm (12.4 X 9.1 X 1.8 inch) |
| Weight | ≤2Kg (4.4lb) |
