| Product Highlights | |
| Technology | HD-TVI |
| Lens | 2.8-12mm |
| Resolution | 2MP/1080p |
FEATURES
- HD-TVI - High Definition Transport Video Interface 1080p FULL HD flawless video
- 1/2.8” Sensor
- 2 Mega Pixels
- Video Output; HD1080P@30fps/25fps
- Smart IR
- 2.8-12mm Vari-focal Mega Pixel Lens
- High-quality IR Cut Filter
- DC 12V
| TIB 1032V | |
| Solution | 1/2.8” Mega Pixel Sensor |
| Signal System | PAL/NTSC |
| Sync. System | Internal Sync. |
| Effective Pixels | 2.0 Mega Pixels |
| Sensing Area | 5.42mm X 3.41mm |
| Horizontal Resolution | PAL:1920X1080P 25F/S NTSC:1920X1080P 30F/S |
| Video Output | 1.0Vp~p75Ω |
| S/N Ratio | More than 50dB (AGC OFF) |
| White Balance | Auto Tracking White Balance |
| Shutter Speed | 1/25-1/50000 |
| Infrared Lamps | Night/Day ON/OFF |
| Minimum Illumination | 0 Lux (Infrared Lamps Turn on) |
| Infrared Wavelength | 850nm |
| IR Leds | 36 Pcs |
| IR Radiation Distance | 30m |
| Built-in Lens | 2.8~12mm Mega Pixel Lens |
| Working Temperature | -10°C~50°C |
| Storage Temperature | -20°C~60°C |
| Power Requirement | DC 12V Max Power Consumption Less Than 5W (when the infrared lamps turn on) |
