4 Ch Standalone Real-Time 120fps DVR (DVST-SD-04)

SKU: 141432
Call for price

Accepted Payments

Live chat
Have a question? ASK AN EXPERT, Call 877-366-2444
Chat Live (Mon–Fri 8am–6pm CT)
Matching or higher specs replacement will be shipped on most analog products, as the technology has been long discounted. all analog sales are final.

Key Features

  • Standard H.264 Compression Format
  • Embedded high-speed microcontroller & Linux system, high stability, auto system upgrading
  • Support Time, Motion searching mode
  • Support mouse, IR remote control
  • Support network remote, USB backup
  • Pentaplex, 4channel playback simultaneously
  • Recording bit/frame adjustable
  • Central Management System
  • Support live display, record, playback, backup, and network
  • Supports 3G, GPRS, WIFI wireless of mobile phone network monitoring function (phone monitoring, capture, PTZ control)
  • Built-in VGA interface, output resolution up to 1024*768
  • More interface; support USB, alarm, intercom, PTZ control
  • Easy & Free Upgrade


Video CompressionH.264® CODEC
Video InputBNC*4 (Composite signal 1.0Vp-p 75Ω)
Output (BNC)BNC*1 (Composite signal 1.0Vp-p 75Ω)
Output (VGA)Built-in VGA interface (1280*1024, 1024*768, 800*600)
Video Record Frame RateNTSC : 30fps/ch
Recording ResolutionNTSC : 360*240 120fps
Operation ModeLive display, Record, Playback, Backup, Network
Recording ModeManual, Time, Motion, Remote
Audio Input/Output1 RCA
Audio encode/decodeADPCM
PTZ Camera ControlYES(Pelco-D&Pelco-P)
HDD Storage1pc SATA HDD
Network InterfaceRJ45(10M/100M adjustable)
Network protocolTCP/IP, UDP, HTTP, NTP, DHCP, DDNS
CMSYES(Maximum:16 different IP addresses)
IR Remote ControlYES
Multilingual OSDYES
Voltage input12V

Write your own review
  • Only registered users can write reviews
  • Bad
  • Excellent
Products specifications
Technology Analog
Number of Channels 4Ch
