| Product Highlights | |
| Number of Channels | 32Ch |
| Technology | Analog |
Key Features
• 32 CH realtime 960H H.264 recording
• HDMI/VGA output is 1920x1080
• Support 1 mainout and 1 spot BNC output; Loop out 32CH
• Intuitive and user-friendly Graphic User Interface(GUI), Windows style operation by mouse
• Multi-mode recording: manual/timer/motion/sensor
• Playback: support 16CH simultaneous playback
• Search: calendar/time, events(alarm, motion)
• Express and flexible backup via USB, network or DVD-RW(SATA)
• Pentaplex: Preview, record, playback, backup and remote access
• DHCP, DDNS, PPPoE network protocol and CMS supported
• Remote control via IE or CMS: preview, playback, backup, PTZ and configuration
• Dual streaming technology to encode recording stream and network stream separately. User can adjust network stream to fit bandwidth without changing recording quality
• Multi-user online simultaneously
• Authorization management, log review and DVR status review
• HDMI 1920x1080 output
• Support PTZ preset and auto cruise, up to 128 presets and 8 cruises
• Powerful smart phone surveillance supporting iPhone/iPad/Android
• Giga Ethernet Interface to get the fastest transmission
Specifications
| D2532HD-C | ||||
| System | Compression Format | H.264 | ||
| OS | Embedded Linux | |||
| Video | Input | 32CH, BNC (1.0Vp-p, 75Ω) | ||
| VGA Output | VGA: 1080P | |||
| BNC | 1 CH | |||
| Loop Output | 32CH | |||
| Spot Output | 1CH | |||
| HDMI | Compatible with HDMI 1920x1080 output, progressive scan, 60Hz frame rate. | |||
| Audio | Input | 16 | ||
| Output | 1 | |||
| Bidirectional Talk | YES | |||
| Recording | ||||
| Realtime | 32CH WD1 | |||
| Recording Mode | Manual,Timer, Motion, Sensor | |||
| Playback | Playback Channel | 16 | ||
| Search Mode | Time, Event, File Management | |||
| Backup | USB Disk | 1 USB 2.0 port | ||
| DVD Burner | - | |||
| Backup Format | DAT or AVI | |||
| Remote Application | Dual Stream | Master stream: 30(NTSC)/25(PAL)fps CIF per channel Network stream: 1/3fps CIF per channel | ||
| Browser | IE, Safari, Chrome, Firefox | |||
| Master Stream in Network | YES | |||
| CMS | Yes | |||
| Mobile Phone | BroView for iPad/iPad2/iPhone/Android | |||
| User Access | 18 users online with professional authority management | |||
| Alarm | Alarm Input | 16 CH | ||
| Alarm Output | 4 CH | |||
| Storage | HDD | 8 SATA | ||
| e-SATA | 1 | |||
| Max HDD after Deploying DVD | 4 | |||
| PTZ | PTZ | 1*RS485 | ||
| PTZ Protocol | PELCOP,PELCOD,LILIN,MINKING,NEON,STAR,VIDO,DSCP, VISCA, SAMSUNG, RM110,HY | |||
| Network | Ethernet | 1000 Mbps Ethernet (RJ-45) | ||
| Protocol | TCP/IP, DHCP, DDNS, NTP, SMTP | |||
| Others | ||||
| Power Supply | 100VAC-240VAC | |||
| Operating Temperature | 0°C ~50°C | |||
| Humidity | 10% ~ 90% Humidity | |||
| Product Dimension | 16.75” (l) x 17.75 (w) x 3.5” (h) | |||
