- 3 megapixel high resolution
- HD real-time video
- Day / night auto switch
- IP66 ingress protection
- Matrix IR illuminator :up to 90ft(about 30m)
- 3D DNR & DWDR
| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.14 [email protected], AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens |
2048X1536: Angle of view:70° 1920X1080: Angle of view:79° |
| Lens Mount | M12 |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Resolution | 2048 × 1536 |
| Frame Rate | 60Hz: 15fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720) 50Hz: 12.5fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| Network | |
| Network Storage | NAS ( iSCSI optional) |
| Alarm Trigger | Motion detection.tampering alarm |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| System Compatibility | ONVIF, PSIA, CGI |
| General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| General | |
| Working Temperature /Humidity |
-25 °C ~ 60 °C (-13 °F ~ 140 °F), humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 9.5W |
| Ingress protection level | IP66 |
| Matrix IR Range | Up to 90ft(About 30 meters) |
| Dimension | 100.5 x 88.1 x 285 mm(3.96"×3.47"×11.22") |
| Weight | 1200g(2.65 lb) |
Products specifications
| Lens | 4mm |
| Technology | IP/Network |
| Resolution | 3MP |
| Camera Features | Outdoor, WDR |
