| Product Highlights | |
| Lens | 4mm |
| Technology | IP/Network |
| Resolution | 2MP/1080p |
| Camera Features | Outdoor, WDR |
- 2.0 megapixel high resolution
- HD video output
- Video Content Analytics(VCA)
- Region of Interest(ROI)
- 3D DNR & DWDR & BLC
- IP66 rating
- IR range: up to 100ft(30m)
- IR cut filter with auto switch
| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.07 lux @F1.2, AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | 4.0 mm @F2.0, Angle of view: 79° |
| Lens Mount | M12 |
| Day & Night | IR cut filter with auto switch |
| Digital Noise Reduction | 3D DNR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| Bit Rate | 32 Kbps ~ 8 Mbps |
| Dual Stream | Yes |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | 60 Hz: 30fps (1920 ×1080), 30fps (1280×960) , 30fps (1280×720) 50 Hz: 25fps (1920 ×1080), 25fps (1280 ×960), 25fps (1280×720) |
| Image Settings | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC | Yes,zone optional |
| ROI | Yes, up to 4 configurable areas |
| Network | |
| Network Storage | NAS |
| Alarm Trigger | Motion detection, Dynamic analysis, Tampering alarm |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP, UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| System compatibility | ONVIF, PSIA, CGI, ISAPI |
| General functionalities | User Authentication, Watermark |
| Interface | |
| Communication Interface | 1 RJ45 10 M / 100 M Ethernet interface |
| Reset Button | Yes |
| General | |
| Working Temperature /Humidity | -22 °F ~ 140 °F(-30 °C ~ 60 °C ) Humidity 95% or less (non-condensing) |
| Power Supply | DC12V±10% / PoE(802.3af) |
| Power Consumption | Max. 7W |
| Weather proof rating | IP66 |
| IR Range | Up to 100ft(30m) |
| Dimension | 2.4" × 3.0" × 5.5"(60.5 x 76.9 x 139.2mm) |
| Weight | 1.1lbs(500g) |
