| Product Highlights | |
| Lens | 4mm |
| Technology | IP/Network |
| Camera Features | Outdoor, WDR |
| Resolution | 4MP |
- 4MP High Definition
- Up to 2560x1440@20fps
- 2.8mm Fixed Lens
- H.265, H.265+, H.264, H.264+ Ready
- DWDR
- IP67
- DC 12V, PoE
- Metal Housing
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 .028Lux @ (F2.0, AGC ON) |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Lens | 4mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117° |
| Lens Mount | M12 |
| Day & Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | DWDR |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0°to 180°, rotation:0° to 360° |
| Compression Standard | |
| Video Compression | Main stream: H. 265/H.264 |
| H.264 / H.264 Zip+ Type | Base Profile / Main Profile / High Profile / Main Stream Supports |
| H.265 / H.265+ Type | Main Profile / Main Stream Support |
| Video Bit Rate | 32 Kbps ~ 8 Mbps |
| Image | |
| Max. Resolution | 2560 × 1440 |
| Main Stream | 50Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream | 50Hz: 20fps (704 × 576, 352 × 288, 640 × 480, 320 × 240) 60Hz: 20fps (704 × 480, 352 × 240, 640 × 480, 320 × 240) |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| ROI | 1 fixed region for main stream and sub-stream |
| Day/Night Switch | Auto / Scheduled |
| Network | |
| Network Storage | NAS (NFS,SMB/CIFS) |
| Alarm Trigger | Motion detection, video tampering alarm, illegal login |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Simultaneous Live View | Up to 6 channels |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| General | |
| Working Temperature /Humidity | -22 °F ~ 122°F (-30 °C ~50 °C) Humidity 95% or less (non-condensing) |
| Power Supply | DC 12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5W |
| IR Range | Approx. 100ft (30 meters) |
| Weather Proof Ratings | IP67 |
| Dimensions | Φ 2.7"× 6.8" (Φ 70 × 172.7 mm) |
| Weight | 0.62lbs (500g) |
