| Product Highlights | |
| Lens | 4mm |
| Technology | IP/Network |
| Resolution | 3MP |
| Camera Features | Outdoor, Vandal Proof, WDR |
- 3.0 megapixel high resolution
- HD real-time video
- Day / night auto switch
- IP66 ingress protection
- IR LEDs :Approx 65 to 100 ft(About 20 to 30m)
- Vandal-proof housing
- 3D DNR & DWDR & BLC
| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.14 [email protected], AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | [email protected] 2048 × 1536: angle of view: 70° 1920 × 1080: angle of view: 79° |
| Lens Mount | M12 |
| Angle adjustment | Pan: 0° ~ 355°, tilt: 0° ~ 65° |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 codec profile | Main profile |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Resolution | 2048 × 1536 |
| Frame Rate | 60 Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720) 50 Hz: 20fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| BLC | Yes,zone configurable |
| Network | |
| Network Storage | NAS ( iSCSI optional) |
| Alarm Trigger | Motion detection,tampering alarm,network disconnect,IP address conflict,storage exception |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| System Compatibility | ONVIF, PSIA, CGI |
| General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| General | |
| Working Temperature /Humidity | -13°F ~ 140°F(-25°C ~ 60°C) humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W |
| Impact protection | IEC60068-275Eh, 50J; EN50102, up to IK10 |
| Ingress protection level | IP66 |
| IR Range | Approx 65 to 100 ft(About 20 to 30m) |
| Dimension | Φ4.4"x3.2"(Φ111.0 × 82.4 mm ) |
| Weight | 1.1lb(500g) |
