| Product Highlights | |
| Lens | 4mm |
| Technology | IP/Network |
| Resolution | 3MP |
| Camera Features | Outdoor, Vandal Proof, WDR |
- 3.0 megapixel high resolution
- HD real-time video
- Day / night auto switch
- IP66 ingress protection
- IR LEDs :Approx 65 to 100ft(About 20 to 30m)
- Vandal-proof housing
- 3D DNR & DWDR & BLC
| Camera | |
| Image Sensor: | 1/3" sensor |
| Min. Illumination: | 0.14 [email protected], AGC ON 0 lux with IR |
| Shutter time: | 1/25s ~ 1/100,000s |
| Lens: | 4.0mm @F2.0 2048 × 1536: angle of view: 70° 1920 × 1080: angle of view: 79° |
| Lens Mount: | M12 |
| Angle adjustment | Pan: 0° ~ 355°, tilt: 0° ~ 65° |
| Digital noise reduction | 3D DNR |
| Wide dynamic range | Digital WDR |
| Day& Night: | ICR |
| Compression Standard | |
| Video Compression: | H.264 /MJPEG |
| H.264 codec profile | Main profile |
| Bit Rate: | 32 Kbps ~ 16 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Image Resolution: | 2048x1536 |
| Frame Rate: | 60 Hz: 20fps (2048 x 1536), 30fps (1920 ×1080), 30fps (1280 x 720) 50 Hz: 20fps (2048 x 1536), 25fps (1920 ×1080), 25fps (1280 x 720) |
| Image Settings: | Saturation, brightness, contrast adjustable through client software or web browser |
| BLC: | Yes, zone configurable |
| Network | |
| Network Storage: | NAS (iSCSI optional) |
| Alarm Trigger: | Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| Security: | User authentication, watermark |
| System Compatibility: | ONVIF, PSIA, CGI |
| General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark |
| Interface | |
| Communication Interface: | 1 RJ45 10M / 100M ethernet interface |
| General | |
| Operating Conditions: | -13°F ~ 140°F (-25°C ~ 60°C) humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: | Max. 5.5W |
| Impact protection | IEC60068-275Eh, 50J; EN50102, up to IK10 |
| Weather Proof: | IP66 |
| IR Range: | |
| Dimensions: | Φ 4.4"× 3.2"(111 × 82 mm) |
| Weight: | 1.1lb(500g) |
