- 2.8mm fixed lens
- 3 megapixel (2048 x 1536) resolution
- Full HD1080p real-time video
- Up to 33ft(10m) IR range
- DWDR & 3D DNR & BLC
- Onboard storage (up to 64GB)
- IP66 protection
- Vandal-proof housing
| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.07 [email protected], AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | [email protected] |
| 2048 × 1536:Angle of view: 86° 1920 × 1080:Angle of view: 98.5° |
|
| Lens Mount | M12 |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Backlight compensation | Yes,zone configurable |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 compression profile | Main profile |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Image | |
| Max. Resolution | 2048 × 1536 |
| Frame Rate | 60Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720) 50Hz: 20fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| Network | |
| Network Storage | NAS ( iSCSI optional) |
| Alarm Trigger | Motion detection, tampering alarm,network disconnect , IP address conflict, storage exception |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP, UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| System Compatibility | ONVIF, PSIA, CGI, ISAPI |
| General functionalities | Flickerless, dual stream, heartbeat, mirror, user authentication, video mask, watermark |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| On-board Storage | Built-in Micro SD card slot, up to 64 GB |
| General | |
| Working Temperature /Humidity |
-30 °C ~ 60 °C (-22 °F ~ 140 °F), humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5W |
| Impact Protection | IEC60068-2-75Eh, 50J; EN50102, up to IK08 |
| Ingress Protection Level | IP66 |
| IR Range | Up to 10m(33ft) |
| Dimension | 99.3 × 96.7 × 52.8mm(3.9" × 3.8" × 2.1") |
| Weight | 600g(1.3lb) |
Products specifications
| Lens | 2.8mm |
| Technology | IP/Network |
| Resolution | 3MP |
| Camera Features | Outdoor, Vandal Proof, WDR |
