Camera |
Image Sensor: |
1/3" Progressive Scan CMOS |
Min. Illumination: |
0.014 lux @F2.0, AGC ON, 0 lux with IR |
Shutter time: |
1/25s ~ 1/100,000s |
Lens: |
2.8mm @F2.0
2048 × 1536: angle of view: 86°
1920 × 1080: angle of view: 98.5°
|
Lens Mount: |
M12 |
Day& Night: |
IR cut filter with auto switch |
Digital noise reduction: |
3D DNR |
Compression Standard |
Video Compression: |
H.264 / MPEG4 / MJPEG |
Bit Rate: |
32 Kbps ~ 16 Mbps |
Image |
Max. Image Resolution: |
2048x1536 |
Frame Rate: |
60Hz: 30fps (1920 × 1080), 30fps (1280 × 720)
50Hz: 25fps (1920 × 1080), 25fps (1280 × 720)
|
Image Settings: |
Saturation, brightness, contrast adjustable through client software or web browser |
BLC: |
Yes, zone configurable |
Network |
Network Storage: |
NAS (iSCSI optional) |
Alarm Trigger: |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
Protocols: |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
Security: |
User authentication, watermark |
System Compatibility: |
ONVIF, PSIA, CGI |
Interface |
Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
General |
Operating Conditions: |
-13°F ~ 140°F(-25°C ~ 60°C ) humidity 95% or less (non-condensing) |
Power Supply: |
12 VDC ± 10%, PoE (802.3af) |
Power Consumption: |
max. 7W |
Weather Proof: |
IP66 |
IR Range: |
Up to 100ft(30m) |
Dimensions: |
Φ5.0"× 3.9"(Φ127.0 x 97.5 mm) |
Weight: |
1.5 lb(670g) |
