| Product Highlights | |
| Lens | 2.8mm |
| Technology | IP/Network |
| Resolution | 1.3MP/960p |
| Camera Features | Outdoor, WDR |
- Up to 1.3 megapixel high resolution
- HD real-time video
- Day / night auto switch
- IP66 ingress protection
- Matrix IR illuminator,up to 100ft(30m)
- 3D DNR & DWDR
| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.028 [email protected], AGC on 0 lux with IR |
| Shutter time | 1/25s ~ 1/100,000s |
| Lens | [email protected] 1280 x 960: angle of view: 92.5° |
| Lens Mount | M12 |
| Angle adjustment | Horizontal: 0° ~ 360°, vertical: 0° ~ 75°, rotation: 0° ~ 360° |
| Digital noise reduction | 3D DNR |
| Wide dynamic range | Digital WDR |
| Day& Night | ICR |
| Compression Standard | |
| Video Compression | H.264 /MJPEG |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Image Resolution | 1280 x 960 |
| Frame Rate | 60Hz: 30fps (1280 x 960), 30fps (1280 x 720) 50Hz: 25fps (1280 x 960), 25fps (1280 x 720 |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| Network | |
| Network Storage | NAS (iSCSI optional) |
| Alarm Trigger | Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| System Compatibility | ONVIF, PSIA, CGI |
| General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark,reset |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet interface |
| General | |
| Operating Conditions: | -13°F ~ 140°F(-25°C ~ 60°C) Humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: | Max. 7W |
| Weather Proof: | IP66 |
| IR Range: | Up to 100 ft(30m) |
| Dimensions: | Φ5.0"x3.8"(127.0 x 97.5 mm) |
| Weight: | 1.5lb(670g) |
