| Product Highlights | |
| Resolution | 1MP/720p |
| Lens | 3.6mm |
| Camera Features | Outdoor |
| Technology | A-HD |
- AHD 720P Real-Time Image, High Resolution, True Color
- Lossless Video Output
- CMOS Progressive Scan, perfectly capture the moving object
- High Speed, Long Distance, Real-Time Transmission
- Auto Color to B / W at Low Illumination
- Support ICR Switch, True Day / Night
- Support Noise Reduction Function
- Up to 100ft IR Night View Distance
- IP66 Weatherproof Casing
| AIR 1022-W | |
| Image Sensor | 1 / 3 "CMOS |
| Resolution | 1280 x 720 |
| Image System | PAL / NTSC |
| Min. Illumination | 0 Lux ( LED ON ) |
| Lens | 3.6 mm Fixed Lens |
| IR Distance | 10~20m |
| Water-proof | IP66 |
| Video Output | BNC x 1 |
| Image Size | 720P ( 1280 x 720 ) |
| Frame Rate | 30 fps ( 60 Hz ), 25 fps ( 50 Hz ) |
| Functions | |
| Day & Night | Yes ( ICR ) |
| S / N Ratio | > 52 dB ( AGC off ) |
| Electronic Shutter | 1 / 50s ~ 1 / 50000s ( PAL ); 1 / 60s ~ 1 / 50000s ( NTSC ) |
| AGC | Yes |
| White Balance | Auto White Balance |
| Others | |
| Power Supply | DC 12V ( ± 10 % ) |
| Working Environment | - 40 °C ~ 70 °C, 10 % ~ 90 % humidity |
| Dimensions | ø64mm × 183mm (ø2.5 in x 7.2 in) |
