Manufacturer: Hikvision

5MP TVI Dome Camera HD 2.7-13.5mm Motorized Lens (AC346D-OD4Z)

SKU: 202075
MPN: AC346D-OD4Z
$170.99
$240.99
Take surveillance to the next level with the (AC346D-OD4Z) Hikvision 5MP Dome Vandal Resistant TVI Camera 2.7-13.5mm Motorized Lens, offering features such as 2.7-13.5mm Motorized Lens, 5MP, HD, 2.7-13.5mm Motorized Lens, 2.7-13.5mm Motorized Lens, HD Over Coax IR Dome. A dependable choice for professional-grade video surveillance.
Share

Share this link via

Or copy link

  • Pay with Ease
    •
    •
    •
    •
  • Secure SSL Encryption
  • Fast, Insured Shipping
  • 30-Day Money-Back Guarantee
  • Hassle-Free Warranty
  • Lifetime Customer Support
Product Highlights
TechnologyHD-TVI
LensMotorized Lens
Resolution5MP
  • HD Over Coax IR Dome
  • Switchable TVI, AHD, CVI, CVBS
  • Starlight Ultra-Low Light Technology
  • 5MP (2592x1944 Resolution)
  • 2.7-13.5mm Motorized Lens
  • Approx 131 FT IR Range
  • 130dB WDR
  • Vandal Resistant
  • 3 Axis Design
  • Dual Voltage
Details
MODEL AC346D-OD4Z
Camera
Image Sensor5MP Progressive Scan CMOS
Effective Pixels2592 (H) x 1944 (V)
Min. IlluminationColor: 0.003 Lux @ (F1.2, AGC On), 0.0 Lux with IR
Frame Rate

TVI: 2MP@30FPS, 4MP@30FPS, 5MP@20FPS

AHD: 4MP@30FPS, 5MP@20FPS

CVI: 4MP@30FPS

CVBS: NTSC

Shutter Time1/30 Sec to 1/50,000 Sec
Lens2.7mm to 13.5mm motorized, Angle of View: 92.3° to 29.3°
Day & NightICR
Wide Dynamic Range130dB
Angle AdjustmentPan: 0° - 355°; Tilt: 0° - 75°; Rotate: 0° - 355°
Menu
Image ModeSTD, High-SAT
AGCYes
Day/Night ModeAuto, color, black and white
White BalanceAuto, manual
AE (Auto Exposure) ModeWDR, BLC, Global
Noise Reduction3D DNR
FunctionsBrightness, sharpness, mirror, smart IR
General
Working Temperature-40°F - 140°F
Power SupplyDual Voltage
Power ConsumptionMax 10.5W
Ingress ProtectionIP67, IK10
IR RangeApprox 131FT
Dimensions7.1" x 4.9"
WeightApprox 2 LBS
