- Indoor 24/7 Full Time Color PTZ
- Smart Motion Detection
- Identification of Human And Vehicle Targets
- H.265+ Video Compression
- 4MP (2560x1440) Resolution
- 2.8-12mm Motorized Lens
- Approx 100FT White Light Range
- 120dB WDR
- 2 Way Audio
- PoE, DC12V
Details
| Model | GNP3A4-LS |
| Camera | |
| Max Resolution | 2560 x 1440 |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC On), 0.0 Lux with white light |
| Shutter Speed | 1/1 sec to 1/30,000 sec |
| Day/Night | 24/7 color |
| WDR | 120dB |
| Main Stream | 60Hz: 30FPS (2560x1440, 1920x1080, 1280x960) |
| Sub-Stream | 60Hz: 30FPS (704x480, 640x480, 352x240) |
| Video Compression | H.265+/H.264+ |
| Lens | |
| Zoom | 4x Optical |
| Focal Length | 2.8-12mm motorized |
| Aperture | F1.0 |
| Illuminator | |
| Supplement Light Type | White Light |
| Supplement Light Range | Approx 100FT |
| PTZ | |
| Movement Range (Pan) | 350° |
| Movement Range (Tilt) | 0° to 90° |
| Pan Speed | Configurable 0.1° to 60°/sec; Preset Speed: 60°/sec |
| Tilt Speed | Configurable 0.1° to 50°/sec; Preset Speed: 50°/sec |
| Presets | 300 |
| Interface | |
| Ethernet | 1 RJ45 10M/100M self adaptive |
| On-board Storage | Built-in memory card slot, up to 256GB |
| Alarm | 1 input, 1 output |
| Audio Input | 1 input (line in) |
| Audio Output | 1 built-in speaker, 1 output |
| Hard Reset | Yes |
| Network | |
| Simultaneous Live View | Up to 20 channels |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS |
| API | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users, 3 user levels: administrator, operator, user |
| Security | Password protection, complicated password, https encryption, IP address filter |
| General | |
| Working Temperature | 40°F ~ 149°F) |
| Power | PoE (802.3at), Max 18W; 12VDC, 3.33A |
| Protection Level | Lightning protection, surge protection, voltage transient protection, IP66 |
| Dimension | 7.06" x 4.72" x 7.71" |
| Weight | Approx 5 LBS |
Products specifications
| Technology | IP/Network |
