- 4K Starlight OmniView
- 180° Panoramic View
- Ultra H.265 CODEC
- 4K (4096x1800) Resolution
- 4 x 2mm Fixed Lens
- Approx 165FT IR Range
- 120dB WDR
- Built-in Micro SD Card Slot
- PoE, AC24V
- Not Compatible with GNR Series NVRs
Details
| Model | GSNCA20-FN |
| Camera | |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Min. Illumination | Color 0.002 Lux @ (F1.8, AGC On), 0.0 Lux with IR |
| Lens | 4 x 2mm Lens |
| Day & Night | IR Cut Filter |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | 120dB WDR |
| Shutter Time | 1 Sec - 1/100,000 Sec |
| Compression Standard | |
| Video Compression | Ultra H.265, H.265, H.264 |
| H.265 Type | Main Profile |
| Video Bit Rate | 128 Kbps - 16 Mbps |
| Image | |
| Max. Image Resolution | 4096 x 1800 |
| Frame Rate |
Main Stream: 4096x1800, Max 30FPS Sub Stream: 1920x832, Max 30FPS |
| Network | |
| Security Measures | User Authentication (ID & PW), Host Authentication (MAC Address), IP Address Filtering |
| User/Host | Up To 32 Users |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP |
| System Compatibility | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host Level | Up To 32 Users, 3 Levels: Administrator, Operator, User |
| Interface | |
| Communication Interface | (1) RJ45 10/100 M Ethernet Interface |
| General | |
| Operating Conditions | -40°F ~ 158°F |
| Power Supply | 24VAC, PoE, Max 24W |
| IR Range | Approx 165FT |
| Dimension | 10.2" x 8.3" x 4.5" |
| Weight | Approx 8 LBS |
Products specifications
| Technology | IP/Network |
