| System |
| Main Processor |
HI3531D*2 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
Default: 16*(EX-SDI: 4K_lite, 4MP; SDI/EX-SDI: 1080P, 720P)
SDI/EX-SDI+Network:14*SDI/EX-SDI+2*network(Max 8MP), 12*SDI/EX-SDI+4*network(Max 8MP)
10*SDI/EX-SDI+6*network(Max 8MP), 8*SDI/EX- SDI+8*network(Max 8MP)
6*SDI/EX-SDI+10*network(Max 8MP), 4*SDI/EX-SDI+12*network(Max 8MP),
2*SDI/EX-SDI+14*network(Max 8MP) Network: 32*network(Max 8MP)
(Total incoming bandwidth ≤160M) |
| Input |
16CH BNC |
| Signal Type |
EX-SDI 4K_lite@12.5/15
EX-SDI 1080P@25/30/50/60, EX-SDI 720P@25/30/50/60
HD-SDI 1080P@25/30/50/60, HD-SDI 720P@25/30/50/60
EX-SDI 1440P@25/30
Network |
| Output |
1 HDMI,1 VGA, 1CVBS |
| Audio |
| Input |
6 Channel, RCA |
| Two-way Audio |
NO |
| Output |
1 Channel, RCA |
| Alarm |
| Sensor Input |
NO |
| Output |
NO |
| Motion Detection |
16Channel(max 32 Channel in pure network mode) |
| Trigger Events |
Recording, Email, Screen tips, Buzzer, Push notifications(motion detection) |
| Email Alarm |
Send Image to The Designated E-mail |
| PTZ |
| Interface |
RS485 |
| Protocol |
Pelco-D, Pelco-P |
| Baud Rate |
110~921600 |
| Address |
0~255 |
| Display |
| VGA |
Resolution: 1920 X 1080P /60Hz, 1280 X 1024 /60Hz, 1280 X 720 /60Hz,1024 X 768 /60Hz |
| HDMI |
Resolution: 3840 X2160/30Hz,2560 X1440/30Hz, 1920 X 1080P /60Hz, 1280 X 1024 /60Hz, 1280 X 720 /60Hz,1024 X 768 /60Hz |
| Display Split |
36 Channel/25 Channel/16 Channel/9 Channel/8 Channel/4 Channel / 1Channel |
| Privacy Masking |
3 Rectangular Zones (Each camera) |
| OSD |
Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Recording |
| Video Compression |
H.265/H.265+/H.264/H.264+ |
| Audio Compression |
G711u |
| Resolution |
8MP_LITE(1920×2160),4MP(2560×1440),1080P(1920×1080),720P(1280×720) |
| Video Quality |
worst/worse/ordinary/well/better/best |
| Record Rate |
SDI/EX-SDI:
8MP_LITE(1920×2160 16*15fps),4MP(2560×1440 16*15fps), 1080P(1920x1080 16*30fps),720P(1280×720 16*30fps), 960H(960×480 16*30fps), D1(720×480 16*30fps), CIF(352×288 16*30fps)
Pure IP:
NTSC: 8MP@17×30fps,5MP@32×30fps,4MP@32×30fps,3MP@32×30fps,1080P@32×30fps, 960P@32×30fps, 720P@32×30fps, D1@32×30fps |
| Record Mode |
Manual\Timer\Motion Detection |
| Playback & Backup |
| Decode Capability |
10CH 1080P@30fps |
| Sync Playback |
Pure SDI/EX-SDI: 8CH 720p@30fps, 8CH 1080p@30fps, 8CH 4MP@15fps
Mix Mode: 4CH 720p@30fps, 4CH 1080p@30fps, 4CH 4MP@30fps, 4CH 5MP@30fps, 2CH 8MP@30fps
Pure IPC: 9CH 720P@30fps, 9CH 960P@30fps, 9CH 1080P@30fps, 8CH 3MP@30fps, 6CH 4MP@30fps, 4CH 5MP@30fps,3CH 8MP@30fps |
| Remote Playback |
4 Channel / 1 Channel |
| Search Mode |
ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions |
Play, Pause, Stop, Fast play, Rewind |
| Smart Phone Playback |
4 Channel |
| Backup Mode |
USB Device/Network |
| Network |
| Interface |
1 RJ45 10M/100/1000M Adaptive Ethernet Interface |
| Network Functions |
TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
| DDNS |
Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES |
| Web Browser |
IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10 |
| Extra Stream |
D1/CIF(1~25fps) |
| Smart Phone |
iPhone, ipad, Android ,Android pad |
| Hard Disk Driver |
| Interface Type |
2 SATA Interface |
| Capacity |
2 SATA Hard Disk (2.5"/3.5" SATA, Up to 16TB) |
| General |
| Language |
Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, Farisa
German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek |
| UTC Control |
YES |
| USB Interface |
2 USB 2.0 Interfaces |
| Power consumption |
DC 12V ≤8W (Without Hard Disk) |
| Working Environment |
-10~55℃/10~90% |
| Dimension (W XD XH) |
310*295*46(mm) |
| Weight |
3.5kg (Without HDD) |
