KEY FEATURES
- 4 HDMI input and 4 HDMI display sink . Any input to any output
- Super IR & RS232 control system, IR transport channel can be forward or backward ,an IR adapter is needed
- HDCP 1.2 compliant
- HDMI1.4a 1080P Full-HD output, deep color 36bit
- Super Slim type,easy to portable
- HDMI digital audio format: DTS-HD/Dolby-true-HD/LPCM7.1/DSD
- Support Xv-YCC and Blue-Ray player for 24fs film format
- Manual or remote or with RS232 controlled by computer select source input signal to different sink
- It can smartly jump over those input sources which are not in work
SPECIFICATIONS
| OP HKTM0404MH | |
| HDMI version | HDMI1.4a with 3D |
| HDCP version | HDCP1.2 |
| Support HDMI resolution | 1080P/1080i/720P/576P/576i/480P/480i |
| Support video color bit | 24bit/deep color 36bit |
| Support audio format | DTS-HD/Dolby-true-HD/LPCM7.1/DSD |
| Date transfer speed | 6.75Gbps |
| Input Video signal | 5.0Volts P-P |
| Input cable distance | <=20m 24AWG Cable |
| Output cable distance | <=20m 24AWG Cable |
| Max working current | 3000mA |
| Power adapter Supply | DC: 5V, 3A |
| Power adapter format | Input: AC (50HZ.60HZ) 100V-240V; Output: DC5V |
| Operating Temperature range | (-15 to +55 Degree) |
| Operating Humidity range | 5 to 90%RH (No Condensation) |
| Dimension (Lx W x H) | 317x256x28(mm) |
| Weight | 1968g |
