| Product Highlights | |
| Number of Channels | 32Ch |
- H.265+ / H.265 dual-stream video compression
- Supports HDCVI / AHD / TVI / CVBS / IP video inputs
- Up to 32 channels of IP camera inputs, each channel up to 8 MP; up to 128 Mbps incoming bandwidth
- Up to 2 channels video stream (analog channel) perimeter protection
- Up to 16 channels video stream (analog channel) SMD plus
- Up to 2 channels video stream (analog channel) human face recognition
- IoT & POS functionalities
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Perimeter Protection | |
| Performance | 2 channels, 10 IVS for each channel |
| Object Classification | Human / vehicle secondary recognition for tripwire and intrusion |
| AI Search | Search by target classification (human, vehicle) |
| Face Recognition | |
| Performance | 2 channels, max 12 face pictures/sec processing 2 channels video stream face recognition, only support analog camera |
| Stranger Mode | Detect strangers' faces (not in device's face database). Similarity threshold can be set manually. |
| AI Search | Up to 8 target face images search at same time, similarity threshold can be set for each target face image. |
| Database Management | Up to 10 face databases with 10,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture. |
| Database Application | Each database can be applied to video channels independently. |
| Event Alerts | Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc. |
| SMD Plus | |
| Performance | 16 channels |
| AI Search | Search by target classification (Human, Vehicle) |
| Audio / Video | |
| Analog Camera Input | 32 channels, BNC |
| HDCVI Camera Input | 5 MP, 4 MP, 1080p @ 25 / 30 fps, 720p @ 50 / 60 fps, 720p @ 25 / 30 fps |
| AHD Camera Input | 5 MP, 4 MP, 1080p @ 25 / 30, 720p @ 25 / 30 fps |
| TVI Camera Input | 5 MP, 4 MP, 1080p @ 25 / 30, 720p @ 25 / 30 fps |
| CVBS Camera Input | PAL / NTSC |
| IP Camera Input | 32 channels, each channel up to 8 MP |
| Audio Channels In / Out | 4 / 1, BNC |
| Two-way Talk | 1 Mic In, 1 Mic Out, BNC |
| Recording | |
| Compression | AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Resolution | 5 M-N, 4 M-N, 1080p, 1080N, 720p, 960H, D1, CIF |
| Record Rate | Main stream: All channel 5 M-N (1 - 10 fps); 4 M-N / 1080p (1 - 15 fps); 1080N / 720p / 960H / D1 / CIF (1 - 25 / 30 fps) Sub stream: D1 / CIF (1 - 15 fps) |
| Bit Rate | 32 Kbps to 6,144 Kbps Per Channel |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 – 60 min (default: 60 min), Pre-record: 1 - 30 sec., Post-record: 10 - 300 sec. |
| Audio Compression | G.711A, G.711U, PCM |
| Audio Sample Rate | 8 KHz, 16 bits per channel |
| Audio Bit Rate | 64 Kbps per channel |
| Display | |
| Interface | 2 HDMI, 1 VGA, 1 TV |
| Resolution | HDMI 1: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI2 / VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-Screen Display | 1 / 4 / 8 / 9 / 16 / 25 / 36 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Network | |
| Interface | 1 x RJ45 Port (1,000 Mbps) |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4 / IPv6, Wi-Fi, 3G / 4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search (supports private IP camera, DVR, NVS, etc.) |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 16.12, CGI Conformant |
| Video Detection and Alarm | |
| Triggered Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm input | 16 |
| Relay Output | 6 |
| Playback and Backup | |
| Playback | 1 / 4 / 9 / 16 |
| Search Mode | Time / Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Storage | |
| Internal HDD | 4 x SATA Ports, up to 10 TB capacity for each disk |
| eSATA | 1 x Port |
| Auxiliary Interface | |
| USB | 3 x USB Ports (1 x USB 2.0; 2 x USB 3.0) |
| RS485 | 1 x Port, for PTZ Control |
| RS232 | 1 x Port, for PC Communication & Keyboard |
| Electrical | |
| Power Supply | 100 ~ 240 V AC, 50 / 60 Hz |
| Power Consumption (Without HDD) | < 22 W |
| Physical Specs | |
| Dimensions | 1.5U, 17.32 × 16.54 × 2.99'' (440 × 421 × 76 mm) |
| Net Weight (without HDD) | 10.7 lb (4.8 kg) |
| Gross Weight | 15.6 lb (7.1 kg) |
| Installation | Desktop / rack mount |
| Environmental | |
| Operating Conditions | 14° to 131° F (-10°C to +55°C), 0 - 90% RH |
| Storage Conditions | -4° to 158° F (-20° to 70° C) , 0 - 90% RH |
| Third-Party Support | |
| Manufacturers | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dahua, Dynacolor, Honeywell, Panasonic, Pelco,Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Certifications | |
| Certifications | FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 |
