| Product Highlights | |
| Resolution | 2MP/1080p |
| Technology | HD-SDI |
| Camera Features | Outdoor |
KEY FEATURES
- 2.0 Mega-Pixel Resolution PTZ
- Optical ×20
- HD-SDI 1080p output @25/30fps
- Service analog video ouput
- Vector Drive and Micro-Stepping Technology make more smooth rotation and accurate preset
- Compound Movement make the speed dome reach preset in shortest route
- True Day & Night with ICR (IR Cut Filter)
- WDR (Wide Dynamic Range)
- DNR (Digital Noise Reduction)
- DSS (Digital Slow Shutter) enhance sensitivity in night time
- HLC (High Light Compensation)
- Defog to clear dome cover by hot air
- 360° endless horizontal rotation
- 90° vertical movement, 180° vertical movement (auto flip on)
- Max. 400°/sec. Preset speed
- 254 presets, 8 auto scan
- 4 pattern, 8 groups could be programmed
- 16 schedule could be programmed by month, week, & day
- Auto focus, auto flip, power up action
- Zoom proportional could be selected
- Powerful park function
- 8 privacy zone could be programmed
- IP66 Outdoor
- Adequate protection against lightening strikes and power surges
- DC12V/AC12V Dual-voltage power supply
- Provide extra DC12V 500mA service power supply for other device (Outdoor)
SPECIFICATIONS
| Image Sensor | 1/2.86” Panasonic CMOS Sensor |
| Video Output | 1080p @25/30fps |
| Zoom | 20× optical zoom / 32× digital zoom |
| Focal Length | F1.6(wide)~3.5(tele); f=4.7~94mm |
| Minimum Illumination | Color:0.5Lux, BW:0.1Lux; Color DSS:0.002Lux, BW DSS:0.001Lux |
| Day & Night | Active/Passive/Day/Night/Schedule |
| Focus | Auto/Manual/Semi-auto |
| Iris | 0---20 |
| Shutter Speed | 1/30(25)---1/60000sec. |
| AGC | Off/On |
| White Balance | Auto |
| Mirror | None/Horizontal/Verical/Horizontal & Vertical |
| WDR | High/Low/Disable |
| Privacy Zone | 8 privacy zone could be programmable |
| DNR | Off / Low / Middle / High |
| Defog | On/Off |
| HLC | On/Off |
| BLC | On/Off |
| Flickerless | On/Off |
| Brightness | Adjustable (0-20) |
| Pan/Tilt Range | Horizontal: 360°(Endless)/Vertical: 90° |
| Speed | Preset : 400° / sec. Manual : 0 ~ 360° / sec. (proportional to zoom ratio) |
| Preset | 254 |
| Auto Scan | 8 |
| Pattern | 4 |
| Group | 8 |
| Schedule | 16 |
| Other functions | Auto Flip, Park Position, Power Up |
| Communication | RS-485 |
| Protocol | Pelco-D, Pelco-P |
| Alarm I/O | 2/1 I/O Alarm |
| Input Voltage | DC 12V/ AC 24V |
| Max. Power Consumption | DC12V: Max.18W; AC24V: Max.31W |
| Dimensions | Ø195mmx192Hmm |
| Weight | Indoor: 1.9Kg(with Ceiling Mount); Outdoor:5.92Kg(PTZ dome and wall/pendant mount) |
| Working Temperature | -42° to 55° |
| Fan/Heater Temperature (Outdoor) | Fan start temp.: Start temp.: 45° and 0°; Heater: 0° |
| Working Humidity | 0%~90% (Non-condensation) |
